Closed-loop pressure regulator
Including controller electronics & SW (plug-and-play)
Normally closed EV design; cycled for pressure control
|
MEOP/Proof/Burst |
320bar (400bar max)/ 480bar/ 800bar |
|
Setting Pressure |
1 – 50 bar |
|
Temperature |
250K – 323K |
|
Mass |
450g |
|
Actuator |
8W/65W at 24-28V, opening time <35 ms |
|
Media |
H2, inter gas, hydrocarbons, storables and more |
|
Maturity |
TRL 5 |
|
Lead times |
14 weeks |
|
MEOP/Proof/Burst |
320bar (400bar max)/ 480bar/ 800bar |
|
Regulated Pressure |
1 – 50 bar |
|
Temperature |
250K – 323K |
|
Mass |
700g |
|
Actuator |
8W/65W at 24-28V, opening time <35 ms |
|
Media |
H2, inter gas, hydrocarbons, storables and more |
|
Maturity |
TRL 5 |
|
Lead times |
14 weeks |
|
MEOP/Proof/Burst
|
320bar (400bar max)/ 480bar/ 800bar
|
|
Regulated Pressure
|
1 – 50 bar
|
|
Temperature
|
160K – 400K
|
|
Mass
|
2500g
|
|
Actuator
|
20W (@20V)/150W at 24-28V, opening time <30/60 ms
|
|
Media
|
H2, inter gas, hydrocarbons, storables and more
|
|
Maturity
|
TRL 5
|
|
Lead times
|
14 weeks
|
