BLDC motor

Cryogenic, space-rated in-runner brushless DC electro motor for both valves and pumps

Scalable to high torque/high rpm applications

Including controller electronics & SW.

Category:

EM50

Typical Applications Valves and Pumps, broad range of applications in cryo & space
Characteristics & Scalability Versatile motor design & controllability, scalable to high torque/high rpm applications
Power / Peak Power 200 W / 500 W
Temperature 20K – 500K
Max. Rotational Speed 3500 RPM
Torque / Peak Torque 0.55 Nm / 1.5 Nm
Max. Voltage 48 V DC
Current / Peak Current 4.5 A / 14.5 A
Maturity TRL 5
Status & Availability Quick scalability to different applications, around 8-12 weeks from PO to delivery

EM60

Typical Applications Test Bench operations, centrifugal pump demonstrator
Characteristics & Scalability High rpm, accompanied by motor controller development
Power 5kW
Temperature 77K – 453K
Max. Rotational Speed 100k RPM
Torque 0.5 Nm
Max. Voltage 340 V DC
Current 22A
Maturity TRL 3
Status & Availability Prototyping phase, scaling to higher power in work
